1-800-BUY-HIFI – www.nilesaudio.com 9
SIGNAL CONNECTORS ANd POwER CONTROLS
SPECIFICATIONS
Driver Complement
SW8: One 8” long-throw front-firing woofer; two 8” long-throw side-mounted
passive radiators
SW6.5: One 6.5” long-throw front-firing woofer; two 6.5” long-throw side-mounted
passive radiators
Amplifier Power
SW8: 1200W dynamic; 300W RMS
SW6.5: 800W dynamic; 200W RMS
Frequency Range
SW8: 36Hz-200Hz
SW6.5 42Hz-200Hz
Power Requirements
SW8 and SW6.5: (switchable) 100~120V~; 220~240V~; 50/60Hz, 2A
Overall Dimensions (with grille)
SW8: 10 3/4” H x 10 1/2” W x 12 1/8” D (27.3cm H x 26.7cm W x 30.8cm D)
SW6.5: 8 5/8” H x 8 3/8” W x 9 5/8” D (21.9cm H x 21.3cm W x 24.4cm D)
Weight
SW8: 16.5 lbs (7.5 kg)
SW6.5: 11 lbs (5.0 kg)
Certification
• Meets FCC Part 15 and ICES-003, Class B for USA and Canada
• CSA Listed and tested under UL/EN60065 standard
• CE compliant for the EU
• C-Tick compliant for Australia and New Zealand
