Service / Repair.
Dismounting of cabinet rear part on following variants: Core 125 Core 130
1. Tools: Screwdriver PH2 (fig.1)
2. Remove the water inlet coupling (fig. 2)
3. Remove the 2 screws to remove the wheels for easy disassembly (fig. 2)
4. Remove the 2 screws behind the wheels (fig.2)
5. Remove the remining 6 screws fixing the cabinet rear part (fig.2)
6. The cabinet rear part can be removed and there is now access to the motor pump unit
Fig. 1
Fig. 2
2
3
4
5
