Nilfisk-ALTO MC 4M Service Manual

B
Technical data
SM MC 3C_ MC 4M Ver.1.0_March 2015
16
Parentitemno: Descripon:
107145840 MC3C‐170/830400/3/50EU
Service data Unit Value
Model
MC 3C-170/830
Item no.
107145840
TECHNICAL DATA
PUMP:
Pressure pump head @ Qiec bar
158
Pressure pump outlet @ Qiec bar
139
Pressure gun outlet @ Qiec bar
127
Retaining pressure* bar
175
Flow. Qiec l/min
11,6
Suction height dry m
-
Suction height primed m
0,5
Pump type
Comet
Number of pistons
3
Piston type
Stainless Steel
Stroke mm
0
Pump oil type
SAE 80W-90 API GL-5
Pump oil amount L
0,42
ELECTRIC:
Electric data
Highvoltage (HV) test voltage kV
1,5
HV Insulation resistance
1
Earth circuit resistance
0,2
Pump revolutions
2880
Electrical diagram no.
71413
UNIT DATA:
Nozzle size, water
NT 0450
Max. Inlet temp. (primed) °C
50
Max. Inlet temp. (suction) °C
50
Max. Inlet temp. (pressure fed) °C
60
Gun Type
ERGO 2000 STANDARD GUN W/O HOSE SWIVEL
Primary Lance Type
FLEXOPOWER PLUS LANCE 990 BEND
Secondary Lance Type
None
Hose
DN6 x 10m
Guarantied sound power
97
Impactfactor calculated
4
Vibration ISO 5349, lance 1 / lance 2
<2,5; +/-1
Protection Class
IPX5
Machine incl. standard acc. kg
35
Size - Machine alone L x W x H mm
382x382x1017
