Nilfisk-ALTO MC 4M Service Manual

F
SM MC 3C_ MC 4M Ver.1.0_March 2015
Service / Repair
44
Remove stainless steel bracket for micro
switch box with a Phillips screwdriver
Pull down the micro switch box
Push out the lock pin for the micro switch
box with a 3 mm Allen key
Micro switch box and cylinder head bolts disassembling
Micro switch box disassembled
Disassemble the 3 cylinder head bolts with
a 10 mm Allen key
Cylinder head bolt disassembled
MC 4M
