Nilfisk-ALTO MC 4M Service Manual

B
Technical data
SM MC 3C_ MC 4M Ver.1.0_March 2015
8
Parentitemno: Descripon:
107146371 MC3C‐150/570230/1/50/13XTUK
Service data Unit Value
Model
MC 3C-150/570 XT
Item no.
107146371
TECHNICAL DATA
PUMP:
Pressure pump head @ Qiec bar
129
Pressure pump outlet @ Qiec bar
126
Pressure gun outlet @ Qiec bar
123
Retaining pressure* bar
172
Flow. Qiec l/min
8,4
Suction height dry m
0,5
Suction height primed m
1
Pump type
NA3
Number of pistons
3
Piston type
Stainless Steel
Stroke mm
0
Pump oil type
SAE 80W-90 API GL-5
Pump oil amount L
0,42
ELECTRIC:
Electric data
Highvoltage (HV) test voltage kV
1,5
HV Insulation resistance
1
Earth circuit resistance
0,2
Pump revolutions
2800
Electrical diagram no.
0
UNIT DATA:
Nozzle size, water
NT 0340
Max. Inlet temp. (primed) °C
25 (50 max.1 hour)
Max. Inlet temp. (suction) °C
25 (50 max.1 hour)
Max. Inlet temp. (pressure fed) °C
60 (>40°C max. 1h)
Gun Type
ERGO 2000 STANDARD GUN W/O HOSE SWIVEL
Primary Lance Type
LANCE FOR 4-IN-1 880 BEND
Secondary Lance Type
None
Hose
DN6X15M
Guarantied sound power
91
Impactfactor calculated
2,6
Vibration ISO 5349, lance 1 / lance 2
<1,5; +/-1
Protection Class
IPX5
Machine incl. standard acc. kg
38
Size - Machine alone L x W x H mm
382x382x1017
