Nilfisk-ALTO NEPTUNE 4 FA User Manual

6
1)
Options / model variants
Original instructions
NEPTUNE 4 FA
1. Insert clamp into the
holder on the sliding
guard:
High-pressure
jet lance
1)
clamp
3.6 Fill up tank for Nilfisk-
ALTO AntiStone
1)
1. Fill up Nilfisk-ALTO Anti-
Stone/water softener reser-
voir with the sample bottle
1)
provided. Nilfisk-ALTO Anti-
Stone prevents any deposits
of scale and acts at the same
time as a corrosion inhibitor.
For compatibility reasons, use
only the tested „Nilfisk-ALTO
Anti-Stone“. Order the refill pack
in good time (Order no. 8466, 6
x 1 l).
3.5 Fill up detergent tank
1)
1. Fill up detergent tank with
prediluted detergent.
Capacity see chapter 9.4 Tech-
nical Data
3.3 Install Crank handle
for high pressure hose
reel
1)
1. Pull cap of crank in arrow di-
rection.
2. Align tabs on crank with slot
in axle.
3. Put crank on axle of high
pressure hose reel.
4. Fix crank by pushing the
cap.
1.
2.
ø
Ø
STOP
3.4 Fit clamp for high-
pressure jet tube
1)

Nilfisk-ALTO NEPTUNE 4 FA Specifications

General

Power Supply	Electric
Frequency	50 Hz
Pump Pressure	120 bar
Water Flow	420 l/h
Voltage/Phase/Frequency	50 Hz
