Nilfisk-ALTO POSEIDON 3 Service Manual

B
Technical data
sm_POSEIDON 3_en_Ver.1.0_11.07
10
DIMENSIONS
3 - 24
*A*
3 - 24
*CH*
POSEIDON 3
UNIT DATA MOTOR
PUMP
Power consumption P1 kW 2,3 2,3
Voltage V 230 / 1 ~ 230 / 1 ~
Current A 10 10
Frequency Hz 50 50
Protection IP X5 X5
Sound pressure LWA dB 95 95
Nozzle - NT 0530 NT 0530
Pressure P1 / P1 max. bar 100 / 165 100 / 165
Recoil force N 24 24
Water discharge (max) l/h 660 660
Water discharge (EN 60335-2-79) l/h 600 600
Suction height (wet) m - -
Water inlet pressure (max) bar 10 10
Water inlet temperature (Pressure mode) °C 60 60
Water inlet temperature (Suction mode) °C 50 50
Pressure (HP-outlet) bar 72 72
Vibrations (ISO 5349) m/s² ≤ 2,5 ≤ 2,5
Type - Capacitor Capacitor
Power kW 2,6 2,6
Voltage V 230 / 1 ~ 230 / 1 ~
Frequency Hz 50 60
Protection IP 54 54
Insulation class Cl F F
Speed r/min 2880 3400
Type - GXR 9,3 GXR 9,3
Plunger type - Steel Steel
Plunger diameter mm 14 14
Wobble disc - 10° 10°
Pump oil - ROTRA THT SAE 90
Amount of oil l 0,18 0,18
Length mm 1020 1020
Width mm 400 400
Height mm 400 400
Weight (XT) kg 34,5 34,5(37)
HP - Hose - DN 6 x 10 m DN 6 x 10 m
Power cord m 6 6
