Nilfisk-ALTO POSEIDON 3 Service Manual

B
Technical data
sm_POSEIDON 3_en_Ver.1.0_11.07
18
DIMENSIONS
3 - 40
*J*
3 - 40
*J*
POSEIDON 3
UNIT DATA MOTOR
PUMP
Power consumption P1 kW 4,2 4,2
Voltage V 200 / 3 ~ 200 / 3 ~
Current A 17,1 17,1
Frequency Hz 50 60
Protection IP X5 X5
Sound pressure LWA dB 95,6 97
Nozzle - NT 0450 NT 0450
Pressure P1 / P1 max. bar 160 / 200 160 / 200
Recoil force N 38 38
Water discharge (max) l/h 825 825
Water discharge (EN 60335-2-79) l/h 750 750
Suction height (wet) m 0,5 0,5
Water inlet pressure (max) bar 10 10
Water inlet temperature (Pressure mode) °C 60 60
Water inlet temperature (Suction mode) °C 50 50
Pressure (HP-outlet) bar 135 135
Vibrations (ISO 5349) m/s² ≤ 2,5 ≤ 2,5
Type - Three-phase Three-phase
Power kW 3 ,7 3 ,7
Voltage V 200 / 3 ~ 200 / 3 ~
Frequency Hz 50 60
Protection IP 54 54
Insulation class Cl F F
Speed r/min 2880 3400
Type - AXR 11,7 AXR 11,7
Plunger type - Steel Steel
Plunger diameter mm 14 14
Wobble disc - 11° 11°
Pump oil - ROTRA THT ROTRA THT
Amount of oil l 0,18 0,18
Length mm 1020 1020
Width mm 400 400
Height mm 400 400
Weight (XT) kg 35 34,5(37)
HP - Hose - DN 6 x 10 m DN 6 x 10 m
Power cord m 6 6
