6
1
Fan motor cover
Titanium tube heat exchanger
15
Handle
2
Front plate
Pipe assembly
16
Wire controller
3
Fan blade
Compressor
17
Back net
4
Fan motor
Power supply waterproof connector
18
Top cover
5
Motor support
Water flow switch
19
Left plate
6
Chassis
Right plate
20
Mainboard
7
Rubber feet
High efficiency finned heat exchanger
21
Top frame
III. Installation Instructions
