Defrosting or defogging:
GUID-11F97BB9-9503-47D0-8BB9-62C812293875
This mode directs the air to the defogger outlets to
defrost/defog the windows.
1. Move the air intake lever to the “
” position.
2. Turn the air flow control dial to the “
” position.
3. Turn the fan speed control “
” dial to the
desired position.
4. Turn the temperature control dial to the desired
position between the middle and the hot (right)
position.
5. Turn the side ventilators to the side windows to
defrost or defog for a clear view to the side
mirrors.
. To remove frost from the outside surface of the
windshield quickly, turn the temperature control
dial to the maximum hot position and the fan
speed control “
” dial to the maximum position.
. If it is difficult to defog the windshield, turn the
“A/C” button on.
Bi-level heating:
GUID-11F97BB9-9503-47D0-8BB9-62C812293875
This mode directs cool air from the side and center
vents and warm air from the foot outlets. When the
temperature control dial is turned to the maximum hot
or cool position, the air between the ventilators and the
foot outlets is the same temperature.
1. Move the air intake lever to the “
” position.
2. Turn the air flow control dial to the “
” position.
3. Turn the fan speed control “
” dial to the
desired position.
4. Turn the temperature control dial to the desired
position.
Heating and defogging:
GUID-11F97BB9-9503-47D0-8BB9-62C812293875
This mode heats the interior and defogs the windows.
1. Move the air intake lever to the “
” position.
2. Turn the air flow control dial to the “
” position.
3. Turn the fan speed control “
” dial to the
desired position.
4. Turn the temperature control dial to the maximum
hot (right) position.
5. Turn the side ventilators to the side windows to
defrost or defog for a clear view to the side
mirrors.
Air conditioner operation
E12-A-120227-1C27FF6F-B0F6-4693-97F4-D539C5928D3F
The air conditioner system should be operated for
approximately 10 minutes at least once a month. This
helps prevent damage to the air conditioner system
due to the lack of lubrication.
Cooling:
GUID-11F97BB9-9503-47D0-8BB9-62C812293875
This mode is used to cool and dehumidify the air.
1. Move the air intake lever to the “
” position.
2. Turn the air flow control dial to the “
” position.
3. Turn the fan speed control “
” dial to the
desired position.
4. Push the “A/C” button on. (The “A/C” indicator
light will illuminate.)
5. Turn the temperature control dial to the desired
position between the middle and the cool (left)
position.
. For quick cooling when the outside temperature is
high, move the air intake lever to the “
”
position. Be sure to move the air intake lever to the
“
” position for normal cooling.
. A visible mist may be seen coming from the
ventilators in hot, humid conditions as the air is
cooled rapidly. This does not indicate a malfunc-
tion.
Dehumidified heating:
GUID-11F97BB9-9503-47D0-8BB9-62C812293875
This mode is used to heat and dehumidify the air.
1. Move the air intake lever to the “
” position.
2. Turn the air flow control dial to the “
” position.
3. Turn the fan speed control “
” dial to the
desired position.
4. Push the “A/C” button on. (The “A/C” indicator
light will illuminate.)
5. Turn the temperature control dial to the desired
position between the middle and the hot (right)
position.
Dehumidified defogging:
GUID-11F97BB9-9503-47D0-8BB9-62C812293875
This mode is used to defog the windows and
dehumidify the air.
1. Move the air intake lever to the “
” position.
2. Turn the air flow control dial to the “
” position.
3. Turn the fan speed control “
” dial to the
desired position.
4. Push the “A/C” button on. (The “A/C” indicator
light will illuminate.)
5. Turn the temperature control dial to the desired
position.
6. Turn the side ventilators to the side windows to
defrost or defog for a clear view to the side
mirrors.
Monitor, Heater and air conditioner, and audio system 4-11
