[ Edit: 2016/ 11/ 24 Model: E12-A ]
Manual operation
E12-A-120227-5ED40235-9A58-40C0-9B7C-8F726571211F
The manual mode can be used to control the heater
and air conditioner to your desired settings. (“MAN-
UAL” will appear on the display.)
To turn off the heater and air conditioner, push the
“OFF” button.
Fan speed control:
GUID-11F97BB9-9503-47D0-8BB9-62C812293875
Push the fan speed control “ ”/“ ” button. Push
the “
” button to increase the fan speed. Push the
“
” button to decrease the fan speed.
Push the “AUTO” button to change the fan speed to
the automatic mode.
Air flow control:
GUID-11F97BB9-9503-47D0-8BB9-62C812293875
Push the “MODE” button to change the air flow mode.
— Air flows from the center and side ventila-
tors.
— Air flows from the center and side ventila-
tors and foot outlets.
— Air flows mainly from the foot outlets
— Air flows from the defogger outlets and foot
outlets.
Temperature control:
GUID-11F97BB9-9503-47D0-8BB9-62C812293875
Push the temperature control “ ”/“ ” button to
set the desired temperature. Push the “
” button to
increase the temperature. Push the “
” button to
decrease the temperature.
Air intake control:
GUID-11F97BB9-9503-47D0-8BB9-62C812293875
. Push the outside air circulation “ ” button to
draw the air flow from outside the vehicle. (The
“
” indicator light will illuminate.)
. Push the air recirculation “
” button to
circulate the air flow inside the vehicle. (The
“
” indicator light will illuminate.)
. If the indicator light on either the outside air
circulation “
” button or the air recirculation
“
” button is illuminated, push and hold the
button with the light illuminated. (The “
” and
“
” indicator lights will blink twice.) The
automatic air intake control mode is set.
SERVICING AIR CONDITIONER
E12-A-120227-A452163A-6EF2-497F-8D8E-005E91C99A28
WARNING:
The air conditioner system contains refrigerant
under high pressure. To avoid personal injury,
any air conditioner service should be done only
by an experienced technician with the proper
equipment.
The air conditioner system in your vehicle is charged
with a refrigerant designed with the environment in
mind.
This refrigerant will not harm the earth’s ozone
layer. However, it may contribute in a small part to
global warming.
Special charging equipment and lubricant are required
when servicing your vehicle’s air conditioner. Using
improper refrigerants or lubricants will cause severe
damage to the air conditioner system.
See “Recommended fluids/lubricants and capacities”
(P.9-2).
A NISSAN dealer will be able to service your
environmentally friendly air conditioner system.
Air conditioner filter
GUID-342DB9C2-7C6F-4911-A7F8-9B9233D0460D
The air conditioning system is equipped with an air
conditioner filter which collects dirt, dust, etc. To make
sure the air conditioner heats, defogs and ventilates
efficiently, replace the filter in accordance with the
specified maintenance intervals listed in the separate
maintenance booklet. To replace the filter, contact a
NISSAN dealer.
The filter should be replaced if air flow is
extremely decreased or when windows fog up
easily when operating heater or air conditioning
system.
Monitor, Heater and air conditioner, and audio system 4-13
