CAUTION:
. Do not scratch the camera lens when clean-
ing dirt or snow.
. The turn signal light may overlap with the
side-of-vehicle line. This is not a malfunc-
tion.
DIFFERENCE BETWEEN PREDICTIVE AND
ACTUAL DISTANCES
GUID-7A1802D0-6CC5-4033-AA1D-B21411528F13
Backing up on a steep uphill
GUID-0797F5FD-4198-4087-A6D7-FF33AC88A9A6
JVH0313X
When backing up the vehicle up a hill, the distance
guide lines and the vehicle width guide lines are shown
closer than the actual distance. For example, the
display shows 1 m (3 ft) to the place
*
A
, but the
actual 1 m (3 ft) distance on the hill is the place
*
B
.
Note that any object on the hill is viewed in the monitor
further than it appears.
Backing up on a steep downhill
GUID-6FDE0834-36A3-455B-8410-091C29CCF873
JVH0314X
When backing up the vehicle down a hill, the distance
guide lines and the vehicle width guide lines are shown
further than the actual distance. For example, the
display shows 1 m (3 ft) to the place
*
A
, but the
actual 1 m (3 ft) distance on the hill is the place
*
B
.
Note that any object on the hill is viewed in the monitor
closer than it appears.
Backing up near a projecting object
GUID-1DB89BD5-AEDF-4830-A01C-D281CE12F7AD
SAA1923
The predictive course lines
*
A
do not touch the
object on the display. However, the vehicle may hit the
object if it projects over the actual moving course.
Monitor, Heater and air conditioner, and audio system 4-5
