[ Edit: 2012/ 4/ 9 Model: E26-A ]
4. Release the parking brake.
5. Attach safety chains whenever towing.
Rear wheels on the ground:
GUID-896AA31A-81D 0-4E9B-81ED-1F58D53AA854
CAUTION:
Never tow Automatic Transmission (AT) model
with the rear wheels on the ground. Doing so will
cause serious and expensive damage to the
transmission. If it is necessary to tow the vehicle,
always use a dolly under the rear wheels or use a
flatbed tow truck.
Manual Transmission (MT) model:
1. Turn the ignition switch to the “OFF” position.
2. Secure the steering wheel in a straight-ahead
position with rope or a similar device.
3. Move the shift lever to the “N” (Neutral) position.
4. Release the parking brake.
5. Attach the safety chains whenever towing.
All four wheels on the ground:
GUID-896AA31A-81D 0-4E9B-81ED-1F58D53AA854
CAUTION:
Never tow AT model with all four wheels on the
ground. Doing so will cause serious and expen-
sive damage to the transmission.
Manual Transmission (MT) model:
1. Turn the ignition switch to the “OFF” position.
2. Move the shift lever to the “N” (Neutral) position.
3. Release the parking brake.
FREEING TRAPPED VEHICLE
GUID-856E0D79-5102-47A1-9A06-4ECA40D22C94
WARNING:
. Never allow anyone to stand near the towing
line during the pulling operation.
. Never spin the tires at high speed. This could
cause them to explode and result in serious
injury. Parts of the vehicle could also over-
heat and be damaged.
In the event that your vehicle’s tires become trapped in
sand, snow, or mud, and the vehicle is unable to free
itself without being pulled, use the recovery hooks.
. Use the recovery hooks only. Do not attach the
pulling device to any other part of the vehicle body.
Otherwise, the vehicle body may be damaged.
. Use the recovery hooks to free a vehicle only.
. The recovery hooks are under tremendous stress
when used to free a trapped vehicle. Always pull
the pulling device straight out from the vehicle.
Never pull on the recovery hooks at an angle.
Front
GUID-91F49354-8E64-44F9-94E4-D9FC42221FAA
JVE0040X
Front
*
1
Remove the hook cover from the bumper with a
suitable tool.
*
2
Securely install the recovery hook as illustrated.
(The hook is stored in the tool bag.)
Make sure that the recovery hook is properly secured
in its storage area after use.
In case of emergency 6-11
