2-4 Instruments and controls
GUID-36B2BBCD-E11F-451D-969A-C754476347C1
JVC0262X
1. Tachometer*
2. Vehicle information display
3. Speedometer*
4. Warning/indicator lights
5. Instrument brightness control switch/Clock ad-
justing knob/Trip computer mode switch
6. Trip computer mode switch/Trip odometer reset
switch
*: The needle indicators may move slightly after the
ignition switch is turned to the “LOCK” position. This is
not a malfunction.
SPEEDOMETER
GUID-C407F3C6-C7D6-4A33-93FF-3811A094897B
JVI0399X
The speedometer indicates the vehicle speed.
TACHOMETER
GUID-4CF3A3B1-A21D-414E-8620-77AC231DCCC5
JVI0401X
The tachometer indicates the engine speed in revolu-
tions per minute (rpm). Do not rev the engine into
the red zone
*
1
.
The red zone varies with models.
METERS AND GAUGES
