[ Edit: 2012/ 4/ 9 Model: E26-A ]
2-24 Instruments and controls
Beverage cooler (if equipped)
GUID-3476EA8D-85F0-4FD5-8BF3-AD8037659FD8
When operating the air conditioner, the drinks can be
kept cool in the pocket.
CONSOLE BOX
GUID-CBE410CF-3CF9-40F9-8C57-2D86727BF485
JVI0437X
To open the center console box, pull the lever up
*
1
and open the lid.
To close, push the lid down.
CUP HOLDERS
GUID-77D305DA-75B9-4016-9A51-680979659792
WARNING:
The driver must not remove or insert cups into
the cup holder while driving so that full attention
may be given to vehicle operation.
CAUTION:
Avoid abrupt starting and braking especially
when the cup holder is being used to prevent
spilling the contents. If the contents are hot, they
could scald you or your passengers.
Front
GUID-BEF17BCC-CD6F-4468-90C5-A52D3553BBE6
JVI0411X
To open the cup holder, pull the holder
*
1
from the
instrument panel.
To close the cup holder, push the holder
*
2
into the
instrument panel.
Rear (if equipped)
GUID-3C057ABB-0010-416F-AFC7-994C5220038E
JVI0457X
The cup holder is located behind the seatback of the
seat. To use the cup holder, push the button
*
1
and
pull the holder down.
CAUTION:
. Store the cup holders when entering or
leaving the rear seat.
. Do not apply an excessive force to the cup
holders.
SOFT BOTTLE HOLDER
GUID-58380EC2-1620-4071-B3CD-D99A77479246
JVI0396X
Front doors
JVI0397X
Sliding doors (if equipped)
The holders are located in the front door and the
sliding door pockets.
