NITEO TOOLS MLTM0037-21 - Page 39

39
7.2 Switching on and o
1. To switch the device on, press the on/o switch (1).
2. To switch the device o, press the on/o switch (1)
again.
7.3 HOLD funcon
The mulmeter has the funcon of storing the currently
displayed measurement result upon pressing the HOLD
buon. Press HOLD again to display the currently
measured value.
7.4 Alternang current (AC) consumpon measurement
( )
1. Connect the black measuring probe to the
socket (5).
2. If the measured current is lower than 200 mA,
connect the red probe to the input
socket (6).
3. If the measured current is higher than 200 mA,
connect the red probe to the socket (7).
4. Use the measurement dial (2) to select the correct
range of AC measurement ( ). If you do not know
the measurement range, rst select the highest
possible range, then switch to lower ones.
5. Connect the measuring ps to the measured part in
series.
6. The mulmeter will measure the value and show the
result on the display.
7.5 Direct current (DC) consumpon measurement ( )
1. Connect the black measuring probe to the
socket (5).
