Q1
BC557
Q2
IRF840, MOSFET
Q3, Q4, Q5, Q7
BC547
Q6
MPSA42
OK1-OK6
EL817, Optocoupler
DIODES
D1
1N4004
D2
1N914
D3
UF4004
LED1-LED6
LED, 3mm
INTEGRATED CIRCUITS
U1
LM7805
U2
MC34063
U3
K155ID1
U4
ATMEGA328P-PU
U5
DS3231
MISCELLANEOUS
PCB
Nixie Clock PCB
BAT_1
CR2032 Battery socket
Battery
3V CR2032
DB1, DB2
Neon bulb
FUSE
0.5A
L1
330uH, 1A Inductor
S1 - S3
Buttons
U3 Socket
16pin socket
U4 Socket
28pin socket
Power socket (JP1)
5.5mm x 2.1mm
Speaker (SP1)
Active alarm buzzer
PCB Spacers
4 PCB spacers
Screws
4 Screws 3mm
J2, J3, J4, J5, DB1, DB2
Pin strips
