Components review
Resistors
1kΩ (R1)
10kΩ (R5, R6, R7, R8, R9,
R10, R11, R14, R17, R18, R19, R20)
470kΩ (R2)
0.5Ω (R4)
3.3kΩ (R3)
330Ω (R12)
270kΩ (R16, R17)
1k (R21)
Components actual view can differ due to different manufacturers.
If an inscription or color bar coding of the component is small, it is necessary to use the
