nLight nPP16 Series - Specifications, Ordering, and Safety; Product Electrical Specifications; Product Physical Specifications; Product Environmental Specifications

ORDERING INFORMATION
(blank)
SW2
SA
SA2
PA
PL T24
Auto On (Switch Ch. 1)
Auto On (Switch Ch. 2)
Manual On (Switch Ch. 1)
Manual On (Switch Ch. 2)
Auto On to 50% (Partial On)
1
Plug Load Control with Occ. only Tracking
2
(CA-T24 Plug Load)
(blank)
D
DS
None
0-10 VDC Dimming Output
(via chase nipple)
0-10 VDC Dimming Output
(via side slot)
Default ModeDimming
nPP16
Series
Power/Relay Pack
nPP16
120/277 VAC
347 VAC
Voltage
(blank)
347
(blank)
LT
Standard
Low Temp
Temp/Humidity
C US LISTED
ASSEMBLED in U.S.A.
WARRANTY
5-year limited warranty. Complete warranty terms located at
www.acuitybrands.com/CustomerResources/Terms_and_conditions.aspx
TITLE 24 SYSTEM COMPONENT
√ Do not exceed maximum wattage, ratings, or published
operation conditions of product.
√ Do not overload.
√ Follow all manufacturer’s warnings, recommendations
and restrictions to ensure proper operation of product.
• To reduce the risk of death, personal injury or property damage from re, electric shock, falling parts, cuts/abrasions, and other hazards please read all warnings and instructions
included with and on the xture box and all xture labels.
• Before installing, servicing, or performing routine maintenance upon this equipment, follow these general precautions.
• Installation and service should be performed by a qualied licensed electrician.
• Maintenance should be performed by qualied person(s) familiar with the products’ construction & operation & any hazards involved. Regular maintenance programs recommended.
READ AND FOLLOW ALL SAFETY INSTRUCTIONS!
SAVE THESE INSTRUCTIONS AND DELIVER TO OWNER AFTER INSTALLATION
• DO NOT INSTALL DAMAGED PRODUCT! This product has been properly packed so that no parts should have been damaged during transit. Inspect to conrm. Any part damaged
or broken during or after assembly should be replaced.
CAUTION: RISK OF PRODUCT DAMAGE
√ Electrostatic Discharge (ESD): ESD can damage product(s). Personal grounding equipment should be worn
during all installation or servicing of the unit.
√ Do not touch individual electrical components, as this can cause ESD and aect product performance.
√ Do not stretch or use cable sets that are too short or are of insucient length.
√ Do not tamper with contacts.
√ Do not modify the product.
√ Do not change or alter internal wiring or installation circuitry.
√ Do not use product for anything other than its intended use.
WARNING - RISK OF BURN or FIRE
CAUTION - RISK OF INJURY
√ Wear gloves and safety glasses at all times when
installing, servicing or performing maintenance.
WARNING - RISK OF ELECTRIC SHOCK
√ Disconnect or turn o power before installation or servicing.
√ Verify that supply voltage is correct by comparing it with the
product information.
√ Make all electrical and grounded connections in accordance with
the National Electrical Code (NEC) and any applicable local code
requirements.
√ All wiring connections should be capped with UL approved
recognized wire connectors.
√ All unused connector openings must be capped.
Sensor Switch 900 Northrop Road, Wallingford, CT 06492 Phone: 1-800.PASSIVE sensorswitch.com/nLight ©2014 Acuity Brands Lighting, Inc. All rights reserved 09/26/14
nPP16 Power / Relay Pack
Sheet#: TN-602-04
3 of 3
ELECTRICAL SPECS
OPERATING VOLTAGE
120/277 VAC
347 VAC (with -347 option)
MAX LOAD: (No derating necessary)
16A @ 120 VAC/ 277 VAC
16A @ 347 VAC (with -347 option)
MAX RECEPTACLE LOAD: 16A @ 120 VAC
MOTOR LOAD: 1 HP
RELAY TYPE: Latching
FREQUENCY: 50/60 Hz
BUS OUPUT CURRENT/VOLTAGE:
40mA / port @ 15 VDC
(non-ER units only)
MAX DIMMING LOAD (with -D option):
Sinks 100 mA; 0-10 VDC dimmable
ballasts or LED drivers
nLIGHT NETWORK PORTS: (2) RJ-45
PHYSICAL SPECS
SIZE: (not incl. 1/2” chase nipple)
3.38” H x 2.53” W x 1.83” D
(8.59 cm x 6.43 cm x 4.65 cm)
WEIGHT: 6 oz
MOUNTING: 1/2” knockout
(7/8” hole) on box or xture
COLOR:
White (Standard)
RED (-ER versions)
BLUE (-PL T24 versions)
SPECIFICATIONS
ENVIRONMENTAL SPECS
OPERATING TEMP:
Standard: 14º to 122º F (-10º to 50º C)
LT Option: -40º to 122º F (-40º to 50º C)
RELATIVE HUMIDITY:
Standard: 20 to 75% non-condensing
LT Option: 20 to 90% non-condensing
ROHS COMPLIANT
SILICONE FREE
UL 2043 Plenum Rated
None
UL924 Emergency
Operation
Emergency
(blank)
ER
Note: For information on current monitoring relay packs, see the nPP16 IM series datasheet.
Notes:
1. Requires D or DS option
2. Not available with D or DS option
