Serial number
Part name
Material
Quantity
Remarks
1
Water tank
ABS
1
With water level
window
2
Float
Foamed PP+magnet
1
3
The front cover
ABS
1
4
Evaporator
Component
1
5
Condenser
Component
1
6
Capillary
Component
1
7
Trachea
TP2Mφ6*0.6
1
8
Exhaust pipe
TP2Mφ6*0.6
1
9
Electric control box
cover
Flame-retardant ABS
1
10
Main control board
Component
1
11
Electric control box
Flame-retardant ABS
1
12
Filter
PP+Nylon mesh
1
Use when with activated
carbon
13
Filter frame
ABS+Nylon mesh
1
14
Operational panel
Component
1
15
Temperature and
humidity sensor
Component
1
16
Top cover
ABS
1
