D isassem b le heat discharg e pipe
1. Remove oint :
remove oint  from oint C.
2. Remove oint A:
Press the clasp and lift oint A upwards to
remove it.
oint 
oint C
upwards
clasp
disassemble
oint A
● Correct installation is as shown in gure (hen installing it on wall, height of hall
should be about 0cm130cm from oor).
● rong installation is shown in following gure (If the pipe is bent too much, it
would easily cause malfunction.)
Installation and disassem b ly of heat discharg e pipe
130cm
40cm
