Nokia 2160 - External Signals and Connections; Fast Travel Charger Connector X130; Phone Charging Connectors X110, X111; Spare Battery Connector X120

After Sales
Technical Documentation
Desktop Charger CHH–2
Page – 5
Original 50/96
External Signals and Connections
The charger has three external connectors, the AC fast travel charger
connector, the phone charging connector and the spare battery connec-
tor.
Fast Travel Charger Connector X130
Pin: Name: Description:
1 VDC Supply voltage input
2 GND Common ground
Phone Charging Connectors X110, X111
Pin: Name: Description:
X110 VC Charge voltage output
X111 PDET/GND Charge detect/phone common ground
Spare Battery Connector X120
Pin/X120: Pin/out: Name: Description:
6, 7, 8 1 VBAT Positive terminal of battery
5 2 BSI Battery size indicator
4 3 BTEMP Battery temperature sensing
input
1, 2, 3 4 GND Common ground
