Nokia 22 User Manual

Setting up the terminal
©2001 Nokia Mobile Phones. All rights reserved. 22
Table 4: IOF light indicators
• If the required values are not obtained, move the terminal to another loca-
tion.
• If you cannot find a place where the signal is stronger than -95 dBm, that is
light indicators 1 and 2 are lit, you can install an external antenna to achieve
proper signalling (See section “ Installing the antenna adapter” on page 23).
• Place the terminal in the desired location.
Making test calls
Make test calls to and from the Nokia 22 using the telephone set connected to
the terminal. To adjust the volume, key in 0**x during the call, the x representing
12345Signal
strength
Blinking----No signal.
On----Approx. -
105dBm
On Blinking---Approx. -
100dBm
On On---Approx. -
95dBm
On On Blinking - - Approx. -
90dBm
On On On - - Approx. -
85dBm
On On On Blinking - Approx. -
80dBm
On On On On - Approx. -
75dBm
On On On On Blinking Approx. -
70dBm
On On On On On Approx. -
65dBm
