Nokia 2505 - Spare Parts Overview

2505 (RM-307)
Nokia Customer Care
Spare Parts Overview
A1 = B Cover Assy
A2 = C Cover Assy
A3 = LCD Module Assy
A4 = A Cover Assy
Only Available as Assembly
＊
A3 = LCD Module Assy
LCD Module Assy
I0013
Lens Protect Film
I0004
Hinge
I0006
A1 = B Cover Assy
＊
B Cover Sub-Assy
I0005
Magnet
I0007
Speaker
I0008
Screw M1.4x2.8
I0003
Right Screw Cover
I0002
Left Screw Cover
I0001
Keymat
I0009
C Cover Sub-Assy
011I0
Shaft Alloy
I0010
A2 = C Cover Assy
＊
Earphone Jack Cover
I0012
A4 = A Cover Assy
A Cover Assy
I0015
Button Stopper
I0014
A1 = B Cover Assy
A2 = C Cover Assy
A3 = LCD Module Assy
A4 = A Cover Assy
Only Available as Assembly
＊
A1 = B Cover Assy
A2 = C Cover Assy
A3 = LCD Module Assy
A4 = A Cover Assy
Only Available as Assembly
＊
A3 = LCD Module Assy
LCD Module Assy
I0013
Lens Protect Film
I0004
Hinge
I0006
A1 = B Cover Assy
＊＊
B Cover Sub-Assy
I0005
B Cover Sub-Assy
I0005
Magnet
I0007
Speaker
I0008
Screw M1.4x2.8
I0003
Right Screw Cover
I0002
Left Screw Cover
I0001
Keymat
I0009
C Cover Sub-Assy
011I0
Shaft Alloy
I0010
A2 = C Cover Assy
＊
Earphone Jack Cover
I0012
A4 = A Cover Assy
A Cover Assy
I0015
Button Stopper
I0014
Issue 1 04/2007 © 2007 Nokia Corporation Company Confidential Page 15
