2505 (RM-307)
Nokia Customer Care
7. Place the SRT-6 into the gap between
C-Cover and D-Cover, move along with
perimeter and lever the snaps to separate
C-Cover and D-Cover. (Left Side)
8. Place the SRT-6 into the gap between
C-Cover and D-Cover, move along with
perimeter and lever the snaps to separate
C-Cover and D-Cover. (Right Side)
9. Place the SRT-6 into the gap between
C-Cover and D-Cover, move along with
perimeter and lever the snaps to separate
C-Cover and D-Cover. (Bottom Side).
10. Pull D-Cover away from hook of C-Cover.
11. Use tweezers to clip white paper sticker
away from FM Shielding Cover.
12. Use tweezers to clip FPC Cable connector
and pull upward to remove it.
