Nokia 2690 User Manual

4 Insert the battery (4), and replace the back cover (5).
Remove the SIM card
Insert a microSD card
Use only compatible microSD cards approved by Nokia for
use with this device. Nokia uses approved industry
standards for memory cards, but some brands may not be
fully compatible with this device. Incompatible cards may
damage the card and the device and corrupt data stored
on the card.
Your phone supports microSD cards with a capacity of up
to 8 GB.
A compatible memory card may be supplied with the
device, and may already be inserted in the device. If not,
do the following:
8Get started
© 2009 Nokia. All rights reserved.

Nokia 2690 Specifications

General

Display Type	TFT, 256K colors
Card Slot	microSD, up to 8GB
Camera	VGA
Bluetooth	2.0, A2DP
Radio	Stereo FM radio, RDS
Network Technology	GSM
GPRS	Class 10
EDGE	Class 10
Status	Discontinued
SIM	Mini-SIM
Phonebook	2000 entries
Call records	Yes
Video	Yes
Loudspeaker	Yes
3.5mm jack	Yes
WLAN	No
USB	microUSB 2.0
Messaging	SMS, MMS, Email, IM
Browser	WAP 2.0/xHTML
Java	Yes, MIDP 2.1
Stand-by	Up to 336 h
Talk time	Up to 4 h 30 min
Display Size	1.8 inches
Resolution	128 x 160 pixels
Battery	Removable Li-Ion battery
Dimensions	107.5 x 45.5 x 13.8 mm
Weight	80.7 g
2G bands	GSM 900 / 1800
Announced	2009, November
Alert types	Vibration, MP3 ringtones
Games	Downloadable
Colors	Blue
SAR	0.79 W/kg (body)
