Nokia 2730c User Manual

Get started
Insert SIM card and battery
Safe removal. Always switch the device off and disconnect the charger before removing
the battery.
The SIM card and its contacts can be easily damaged by scratches or bending, so be
careful when handling, inserting, or removing the card.
1 Press and slide the back cover towards the bottom of the phone, and remove it (1).
2 Remove the battery (2).
3 Open the SIM card holder (3), insert the SIM card with the contact surface facing
down (4), and close the holder (5).
4 Insert the battery (6), and replace the back cover (7).
Insert a microSD card
Use only compatible microSD cards approved by Nokia for use with this device. Nokia
uses approved industry standards for memory cards, but some brands may not be fully
compatible with this device. Incompatible cards may damage the card and the device
and corrupt data stored on the card.
Your phone supports microSD cards with a capacity of up to 2 GB.
A compatible memory card may be supplied with the device, and may already be
inserted in the device. If not, do the following:
1 Open the cover of the memory card slot.
Get started 5
© 2009 Nokia. All rights reserved. 5

Nokia 2730c Specifications

General

Display	TFT, 256K colors
Internal Storage	30MB
Main Camera	2 MP
Battery	Removable Li-Ion 1020 mAh battery (BL-5C)
Weight	87.7 g (3.07 oz)
Network Technology	GSM / HSPA
2G bands	GSM 850 / 900 / 1800 / 1900
3G bands	HSDPA 900 / 2100
Speed	Yes, 384 kbps
GPRS	Class 32
EDGE	Class 32
Status	Discontinued
SIM	Mini-SIM
Call records	Yes
Video	Yes
Alert types	Vibration, MP3 ringtones
Loudspeaker	Yes
3.5mm jack	No
WLAN	No
GPS	No
Radio	Stereo FM radio, RDS
Messaging	SMS, MMS, Email, IM
Browser	WAP 2.0/xHTML, HTML
Java	Yes, MIDP 2.1
Resolution	240 x 320 pixels
Card Slot	microSD, up to 2 GB
Announced	2009, May
Released	2009, June
Phonebook	2000 entries
Bluetooth	v2.0, A2DP
USB	microUSB 2.0
Games	Yes
Talk time	Up to 3 h 30 min (3G)
Colors	Black, Red
