Nokia 3330 Service Manual

PAGE 6 (21) Approved 2.0
Nokia Mobile Phones Customer Care E&A
SQX 00451-en MWy
Technical Services, Repair Concepts Confidential 27.05.2002
2. BILL OF REPAIR
SPARE PARTS
ITEM/
CIRCUIT REF.
QTY PART NO PART NAME
I003 6 6290107 SCREWS
I004 1 4850123
DISPLAY ASSEMBLY 3310/3330
I004 1 4850221
DISPLAY ASSEMBLY 3410
I005 1 5140067 SPEAKER
I005 1 9480588 SPEAKER GASKET
I007 2 5400171 ANTENNA POGO PIN DMS02722 SPR
I008 1 5460039 SYS CONN ASSY SPR. 5AF+5DC+MIC
I009 1 5140191 BUZZER ASSY DMC02718 HDA12
I010 1 9790437 POWERKEY DMD05798-EN HDA12
I011 1 5400169 SIM CONN 2X3POL P2.54 SPR 15V 1A
I012 1 6800049 VIB MOT ASSY 1.3V 115MA 9500RPM
I014 1 5409153 SM BATT CONN 4POL SPR 200V 2A
I015 1 9460355 BATTERY LOCK DMD05789 HDA12
I016 1 0660212 INT. PIFA EGSM/PCN (ANTENNA)
Service Manual 3310/3330/3410 Level 1 Copyright 2002 © Nokia Corporation

Nokia 3330 Specifications

General

Network	GSM 900 / 1800
Display Type	Monochrome graphic
Resolution	84 x 48 pixels
Phonebook	100 entries
Call records	10 dialed, 10 received, 10 missed calls
Games	Snake II, Pairs II, Space Impact, Bantumi
SIM	Mini-SIM
Alert types	Vibration; Downloadable monophonic ringtones
Messaging	SMS
Clock	Yes
Alarm	Yes
Java	No
Predictive text input	Yes
Calculator	Yes
Currency converter	Yes
Weight	133 g
Stand-by	up to 260 h
Talk time	1 h 30 min - 4 h 30 min
Colors	Blue, Red
WAP	1.1
Dimensions	113 x 48 x 22 mm
