Nokia 3330 - Main Parts

PAGE 16 (21) Approved 2.0
Nokia Mobile Phones Customer Care E&A
SQX 00451-en MWy
Technical Services, Repair Concepts Confidential 27.05.2002
6. MAIN PARTS
S
p
eaker
I005
Buzzer
I009
SIM Connector
I011
Microphone not changeable
System Connector
I008
Keymat
I002
Battery Connector
I014
Vibra Motor
I012
Antenna Po
g
o Pins
I007
Battery Lock
I015
A-Cover
I001
D-Cover, not changeable
Dis
p
lay Assembly
I004
Service Manual 3310/3330/3410 Level 1 Copyright 2002 © Nokia Corporation
