Nokia 3330 Service Manual

PAGE 8 (21) Approved 2.0
Nokia Mobile Phones Customer Care E&A
SQX 00451-en MWy
Technical Services, Repair Concepts Confidential 27.05.2002
VARIANT PARTS 3330
ITEM/
CIRCUIT REF.
QTY PART NO PART NAME
I001 1 9452043 A-COVER ASSEMBLY NAVY BLUE
I001 1 9452038 A-COVER ASSEMBLY POLAR BLUE
I001 1 9452039 A-COVER ASSEMBLY VESUVIUS RED
I001 1 9452040 A-COVER ASSEMBLY HIMALAJA WHITE
I001 1 9452041 A-COVER ASSEMBLY SAHARA YELLOW
I001 1 9452042 A-COVER ASSEMBLY ICEBER GREY
I001 1 9452037 A-COVER ASSEMBLY ARCTIC SILVER
I002 1 9790420 KEYMAT ENGLISH
I002 1 9790576 KEYMAT CYRILLIC
I002 1 9790466 KEYMAT HEBREW
I019 1 9451797 B-COVER ASSEMBLY NAVY BLUE
I019 1 9451821 B-COVER ASSEMBLY POLAR BLUE
I019 1 9451836 B-COVER ASSEMBLY VESUVIUS RED
I019 1 9451834 B-COVER ASSEMBLY HIMALAJA WHITE
I019 1 9451832 B-COVER ASSEMBLY SAHARA YELLOW
I019 1 9451841 B-COVER ASSEMBLY ICEBER GREY
I019 1 9451915 B-COVER ASSEMBLY ARCTIC SILVER
VARIANT PARTS 3410
ITEM/
CIRCUIT REF.
QTY PART NO PART NAME
I001 1 9458276 A-COVER ASSEMBLY
I002 1 9790657 KEYMAT LATIN
I002 1 9790658 KEYMAT CYRILLIC
I002 1 9790695 KEYMAT HEBREW
I002 1 9790698 KEYMAT ARABIC
I019 1 9458278 B-COVER ASSEMBLY
Service Manual 3310/3330/3410 Level 1 Copyright 2002 © Nokia Corporation

Nokia 3330 Specifications

General

Network	GSM 900 / 1800
Display Type	Monochrome graphic
Resolution	84 x 48 pixels
Phonebook	100 entries
Call records	10 dialed, 10 received, 10 missed calls
Games	Snake II, Pairs II, Space Impact, Bantumi
SIM	Mini-SIM
Alert types	Vibration; Downloadable monophonic ringtones
Messaging	SMS
Clock	Yes
Alarm	Yes
Java	No
Predictive text input	Yes
Calculator	Yes
Currency converter	Yes
Weight	133 g
Stand-by	up to 260 h
Talk time	1 h 30 min - 4 h 30 min
Colors	Blue, Red
WAP	1.1
Dimensions	113 x 48 x 22 mm
