Nokia 3510 Repair Guide

CONFIDENTIAL
6 (18)
Customer Care Europe, Middel East & Africa NHM-8 / RH-9 Repairhints
SCCE Training Group Version 2.0 Approved
 2003 Nokia Mobile Phones
Date 10-03-2003
© NMP 2003
Checked by: SCCE Approved by: Training Group
CHAPTER 1: List of figures
Figure Chapter Page
1: 32.768kHz sinewave at C209 3 9
2: 32.768kHz sinewave at C210 3 9
3: 26MHz sinewave at B600 3 9
4: 26MHz reference clock at J425 (measured with spectrum analyzer) 3 10
5: 32.768kHz SLEEPCLK squarewave at J404 3 11
6: 26MHz reference clock at J425 (measured with oscilloscope) 3 11
7: VSIM measured without SIM card at pogo pins of service jig 5 13
8: 26MHz reference clock at J425 (measured with oscilloscope) 8 16
9: TXC at R637 (TX powerlevel 10) 8 16
10: TXP at C646 8 16
11: TXIQ at R610 / R611 8 16
12: RFBusData at J610 8 16
13: RFBusClock at J608 8 16
14: RFBusEnable at J609 8 16
15: VPCTRL_G at R713 8 17
16: VTX_B_G at R717 8 17
17: VTXLO_G at R716 8 17

Nokia 3510 Specifications

General

Network	GSM 900 / 1800
Display Type	Monochrome graphic
Messaging	SMS
GPRS	No
Announced	2002, Q1
Status	Discontinued
SIM	Mini-SIM
Memory Card slot	No
Call records	10 dialed, 10 received, 10 missed calls
Loudspeaker	No
Alert types	Vibration; Downloadable monophonic ringtones
3.5mm jack	No
Clock	Yes
Alarm	Yes
Predictive text input	Yes
Reminders	Yes
Java	No
Weight	106 g
Games	3 - Snake II
Colors	Blue, Red
Resolution	96 x 65 pixels
