Nokia 3510 - Bill of Repair

PAGE 6 (17) Approved 1.0
Nokia Mobile Phones Customer Care E&A
SQX 00443-en MWy
Technical Services, Repair Concepts Confidential 22.05.2002
2. BILL OF REPAIR
ITEM/
CIRCUIT
REF.
QTY PART NO PART NAME
I003 6 6290107 SCREW 1.8X7.0 FE T6+
I004 1 4850247 DISPLAY ASSEMBLY
A901 1 9517120 BB SHIELD LID
I019 1 9517121 METAL FRAME ASSY
I018 1 5140067 SPEAKER+SPRING 103+-3DB 32R D13.2 (EARPIECE)
I006 1 5140243 SALT SPEAKER
I007 1 5409159 BOTTOM CONNECTOR (WITHOUT MICROPHONE)
I021 1 5140201 MICROPHONE -42dB +-3dB
I008 1 6800053 VIBRA MOT ASSY 1.3V 115MA 9500RPM
I009 1 9517122 SIM CARD SUPPORT
I010 1 5400253 BATTERY CONNECTOR
I014 1 9510854 RELEASE SPRING CLOSED
F100 1 5119019 SM FUSE F 1.5A 32V 0603 1.5A
S300 1 5209001 SM SW TACT SPST 12V 50MA SIDE KEY
V301 1 4860401 LED LNJ322W830NK 575NM 90DEG TBSF
V302 1 4860401 LED LNJ322W830NK 575NM 90DEG TBSF
V308 1 4860401 LED LNJ322W830NK 575NM 90DEG TBSF
V309 1 4860401 LED LNJ322W830NK 575NM 90DEG TBSF
VARIANT PARTS
ITEM/
CIRCUIT
REF.
QTY PART NO PART NAME
I001 1 9490588 A-COVER Assembly DARK BLUE
I001 1 9490590 A-COVER Assembly BURGUNDY
I001 1 9490589 A-COVER Assembly WHITE
I002 1 9794055 KEYMAT LATIN
I002 1 9794104 KEYMAT ARABIC
I002 1 9794107 KEYMAT CYRILIC
I002 1 9794105 KEYMAT GREEK
I002 1 9794106 KEYMAT HEBREW
I011 1 9790514 POWER KEY LIME GREEN
I017 1 9490585 B-COVER ASSEMBLY LIGHT BLUE
I017 1 9490587 B-COVER ASSEMBLY BURGUNDY
I017 1 9490586 B-COVER ASSEMBLY GREEN
Service Manual 3510 Level 2 Copyright 2002 © Nokia Corporation
