Component Finder
| 5230 RM-629 | Board: 3CB_05g | v1.0 | 01.03.2010
Bottom
Top
C2122 L5 C2459 E3 C3207 K7 C7550 C9 L2505 C1 R1410 O3 R7526 B5
A1400 Q3 C2123 L5 C2460 E3 C3301 Q7 C7553 D8 L2506 E2 R1413 Q4 R7527 B6
A2000 Q6 C2124 K5 C2461 E3 C3305 R7 C7580 C2 L3300 R7 R1414 P2 R7528 D6
A2300 J4 C212 5 K5 C2462 E4 C3306 Q7 C7581 B3 L6000 L4 R2000 S1 R7541 B9
A2800 F6 C2126 K6 C2463 E4 C3307 R6 C7582 B2 L6 0 0 1 L3 R2007 Q6 R7543 C8
A3300 Q6 C2127 K6 C2464 F4 C6003 L3 C7583 B3 L6002 L2 R2010 R6 R7544 C8
A6000 L3 C2129 L6 C2465 E4 C6004 L3 C7590 D4 L6003 L2 R2011 R6 R7560 B7
A6200 Q8 C2130 L6 C
2470 S7 C6005 L3 C7591 D4 L6004 L2 R2017 Q6 R7596 F2
A7500 C6 C2131 L5 C2471 S8 C6006 K3 C7595 E2 L6200 Q8 R2018 Q6 R7597 E2
C2132 L5 C2472 S7 C6007 L3 C7596 E2 L6201 Q8 R2019 Q6
B2170 B7 C2133 L5 C2473 S7 C6008 K3 L7500 C 4 R2020 Q6 S2500 B1
B2200 J4 C2137 R5 C 2 7 0 0 M9 C6009 K2 D1400 P3 L 7 5 0 1 C4 R2071 T2 S2502 Q1
C2158 L5 C2800 E7 C6010 K4 D2800 F5 L7502 D4 R2100 S6 S2503 N1
C1401 R3 C2159 L4 C2801 H5 C6012 K4 D2850 I4 L7503 B2 R2101 S5 S2504 T2
C1403 Q4 C2170 B8 C2802 E5 C6013 K3 D3000 F8 L7506 D3 R2120 R5 S2
505 G1
C1405 P4 C2173 H4 C2803 H5 C6014 L4 D3300 Q7 L7510 D7 R2121 K5
C1406 O4 C2201 I3 C2804 G4 C601 5 L2 L7540 C 8 R2170 H4 T7502 D5
C1407 R2 C2203 K3 C2805 H6 C6016 L2 F2000 S2 L7550 C9 R2200 K3 T7580 B5
C1408 O2 C2205 J4 C 2 8 0 6 E6 C6017 L2 L7586 C4 R2201 H4
C1410 R2 C2211 I2 C2807 E4 C6022 L4 G6200 Q8 L7587 C4 R2300 B3 V20 0 0 Q6
C1411 P4 C2213 I3 C2808 F4 C6023 K2 G7501 D3 L7588 D4 R2440 J2
C1412 P4 C2215 I3 C2809 G4 C6024 L2 L7590 D5 R2441 S7 X1450 Q3
C1413 Q4 C2216 I4 C2810 E7 C6200 Q8 L1401 R3 L7591 C9 R24
55 R4 X2010 T5
C1414 R4 C2217 K3 C2811 H7 C6201 Q8 L1403 R4 L 7 5 9 2 D5 R2457 R4 X2060 Q1
C1415 R3 C2220 J2 C2812 E6 C6202 Q8 L1405 O4 L7593 F2 R2800 F4 X2070 C3
C1416 P3 C2222 I3 C2813 H5 C6203 R8 L2000 S1 R2830 K4 X 2 4 0 1 T2
C1417 O3 C2225 I4 C2814 H5 C6204 Q8 L2004 Q5 M2110 S2 R2850 L6 X2450 S6
C1418 R2 C2226 I4 C2815 E6 C6205 R8 L2005 Q6 R2851 L6 X2470 T8
C1419 P3 C2227 I3 C2816 G4 C6206 R8 L2006 Q6 N1400 Q3 R2852 H2 X2500 D1
C1420 R2 C2228 I3 C2817 E7 C6207 Q8 L200 7 Q5 N1402 O3 R2853 H2 X2700 N8
C1421 O3 C223
1 J2 C2818 E5 C6209 R8 L2010 R5 N1403 R2 R2854 E5 X32 0 0 J8
C1422 P2 C2232 I3 C2819 F4 C6210 R8 L2011 Q5 N1404 O2 R2856 H6 X3300 T8
C1425 Q4 C2235 J5 C 2 8 2 0 H6 C6211 Q8 L2100 S5 N2121 K5 R2857 H6 X6200 I9
C1454 Q2 C2236 I6 C2821 H5 C6212 R8 L2110 J2 N2122 R5 R2860 E4 X6400 J1
C1455 Q2 C2237 J2 C 2 8 2 2 E5 C6500 P6 L21 1 1 K2 N2200 J3 R2861 E6 X7501 B4
C1463 P2 C2238 J3 C2823 H7 C6501 T2 L2121 K5 N2201 I5 R2862 I4
C2000 S1 C2239 I5 C2824 F7 C6503 K7 L2154 L 4 N2300 J5 R2865 I4 Z2010 Q5
C2001 R1 C2240 I6 C2825 E6 C6505
Q6 L2155 L4 N2301 I1 R3201 L8 Z2450 S8
C2010 R5 C2303 J5 C2826 G7 C6506 S2 L2156 S8 N2390 G4 R3300 R7 Z2500 G2
C2012 Q5 C2304 J4 C 2 8 2 7 G7 C65 0 7 S2 L2157 S7 N2420 G2 R3302 R7 Z3300 R7
C2013 Q5 C2307 I5 C2828 E4 C6508 Q6 L2202 I4 N2450 R3 R3303 R7 Z3301 R7
C2019 Q6 C2312 J5 C 2 8 2 9 F7 C7 5 0 0 D2 L2205 J2 N2460 F3 R3304 J4 Z6000 L2
C2020 Q7 C2390 G4 C2852 I4 C7507 D3 L2206 I5 N3200 L8 R3305 J4 Z6200 Q8
C2021 Q6 C2391 H3 C3000 H7 C7513 C2 L2390 G3 N6000 L3 R6000 F2 Z7501 C5
C2022 Q7 C2392 G4 C3001 H8 C7517 B3 L2391 G
3 N6200 R8 R6006 K3 Z7503 C5
C2023 Q7 C2393 G3 C3002 E8 C7518 B4 L2440 I2 N6501 L7 R6008 K2 Z7504 C4
C2071 C5 C2420 H2 C3003 E8 C7519 C2 L2444 I1 N7505 C3 R6010 M4 Z7521 D6
C2072 C5 C2421 G3 C3004 E9 C7520 C2 L2450 T6 N7520 C6 R6201 F 2 Z7540 D7
C2073 C5 C2440 I2 C3005 H7 C7521 B7 L2451 T6 N7540 D9 R6500 S2 Z7541 C7
C2074 C5 C2441 I1 C3006 H8 C7523 D7 L2452 S5 N7541 B9 R6501 P6 Z7580 B4
C2075 C5 C2442 J1 C3007 E7 C7524 C5 L2453 T5 N7590 D4 R7501 C2 Z7582 D4
C2076 C2 C2444 T7 C3008 H8 C7525 B5 L2470 S8 R7502 B3
C2077 H 2 C2445 J1 C3009 E9 C7543 C8 L2471 S7 R1400 Q4 R7503 B4
C2110 J2 C2452 S4 C3100 L6 C7544 C9 L2500 E1 R1401 R2 R7509 D3
C2111 K2 C2453 T6 C3 2 0 0 L9 C7545 C 9 L2501 E1 R1402 R3 R7522 D4
C2112 J1 C2454 T5 C3201 L8 C754 7 B9 L2502 E2 R1405 R3 R7523 B6
C2120 K5 C2455 S5 C3204 L8 C 7 5 4 8 C9 L2503 C2 R1406 R3 R7524 B6
C2121 L5 C2456 T5 C3205 K9 C7549 D8 L2504 C1 R1409 P4 R7525 B5
X
Z
L
M
N
R
S
T
D
F
A
B
C
