Nokia 5510 Troubleshooting

NPM-5
CMT Troubleshooting PAMS Technical Documentation
3DJH 1RNLD&RUSRUDWLRQ ,VVXH
7URXEOHVKRRWLQJ&KDUWVIRU&07
3KRQHLV'HDG
3KRQHLVGHDGPHDQVWKDWWKHSKRQHGRHVQRWWDNHFXUUHQWZKHQWKHSRZHUVZLWFKLV
SUHVVHGRUZKHQWKHZDWFKGRJGLVDEOHSLQ:'',6;LVJURXQGHG1RPLQDOVXSSO\YROWDJH
WRWKHSKRQHLV99EDWYROWDJH,IWKHEDWWHU\YROWDJHLVEHORZ9WKH&&217SUH
YHQWVWKHSKRQHIURPSRZHULQJXS
)LJXUH'HDGSKRQH
The phone is dead
The voltage at C404, C202,
C226, C227, C228 is = 3,6V
Failiure in Vbatt line.
Check X203, R220.
No
Voltage on R224 = 3,6V
Defective N201 or
PCB
Yes
No
Voltage at C316= 2,8V
Voltage at C243 = 2,8V
when WDDISX is grounded
Yes
WDDISX = 0 when
PWR switch is pressed
No
Defective CCONT
(N201)
Yes
Check power switch
Check WDDISX line :
PWR switch -> R402
->R224
No
Defective PCB
Ok
See section "Phone is
unable to stay ON"
Yes
