Nokia 5510 Troubleshooting

PAMS Technical Documentation RF Troubleshooting
NPM-5
,VVXH 1RNLD&RUSRUDWLRQ 3DJH
 7URXEOHVKRRWLQJFKDUWIRU*60UHFHLYHU
)LJXUH3&1IDXOWWUHH
)LJXUH3&1RVFLOORVFRSHVFUHHQVKRW
Apply -80dBm
1842.867MHz signal
from generator to
antenna connector
Oscilloscope at RXI
Signal 1.5Vpp
DC offset 1,1V
Frequency 67,7kHz
EGSM chain functional
Oscilloscope
VRX 2.7V
Check Hagar serial
interface
Yes
Yes
Yes
Spectrumanalyzer
V500, RFout
-72dBm
No No
Spectrumanalyzer
1st Dual RX SAW
In2
-92dBm
PCN_RX
-91.5dBm
No
Spectrumanalyzer
T500, unbal
-79.5dBm
Check
C519,L521, Z500
No
Yes
Check Hagar
N500
Yes
Check BBNo
Oscilloscope
LNAB_G 2.4-2.8V
LNA_P 0V
Yes
Check RX/TX
Switch
Z502
No
Check Z500
Yes
PCN Fault tree
No
Oscilloscope
V500, RFout 2.1-2.2V
V500, RFin 0.8-0.9V
Yes
Oscilloscope
VRX 2.7V
Check Hagar serial interface
Check Hagar
N500
Yes
Check BaseBandNo
Check
R503, L502,
V500, C519,
C521, C523,
C525, L505, C510
No
Check
V500
Yes
Change generator
level to -55dBm
Yes

Nokia 5510 Specifications

General

Display	Monochrome graphic
Weight	155 g
Keyboard	QWERTY
Network Technology	GSM
2G bands	GSM 900 / 1800
GPRS	No
EDGE	No
Announced	2001
Status	Discontinued
SIM	Mini-SIM
Phonebook	Yes
Call records	10 dialed, 10 received, 10 missed calls
Loudspeaker	Yes
Alert types	Vibration; Downloadable monophonic ringtones
3.5mm jack	No
Games	Yes
Messaging	SMS
Clock	Yes
Alarm	Yes
Infrared port	Yes
Music player	Yes
Radio	Stereo FM radio
Java	No
Dimensions	134 x 58 x 28 mm
Stand-by	55 h - 260 h
Talk time	Up to 4 h 30 min
Colors	Blue
Battery	Removable Li-Ion 950 mAh battery (BLC-2)
