Nokia 5510 Troubleshooting

NPM-5
UI Module Troubleshooting PAMS Technical Documentation
3DJH 1RNLD&RUSRUDWLRQ ,VVXH
86%&RQQHFWLYLW\)XQFWLRQ
)RUWKLVVHFWLRQLWLVDVVXPHGWKHVHUYLFHFHQWHUKDVD3&DQGVSHFLDOYHUVLRQRI1$0
VXLWDEOHIRUPXOWLSOH130FRQQHFWLRQ
7KHVHPDLQGHYLFHVDUHWREHLQJRRGFRQGLWLRQIRUWKHPXVLFSOD\HUWRIXQFWLRQSURSHUO\
• U301 MCU
• U101 DSP
• U201 NAND Memory
• U401 USB
Diagnostic Tests:
• Check presence of VBAT, VBB and UC_VCC, DVCC, AVCC, CVCC,
USB_VCC (Table 7, “UI module voltages,” on page 73)
• Check operating current during USB mode (Table 8, “UI current consumption
in normal conditons,” on page 73).
• Check presence of clock frequency 32.768kHz @ U301-Pin9 using oscillo-
scope (Table 47, “MCU Clock Waveform – 32.768kHz,” on page 74).
• Check presence of clock frequency 11.9952MHz @ U101-Pin97 and U601-
Pin25 (Table 48, “DSP Clock Waveform – 11.9952MHz,” on page 75).
• Check presence of clock frequency 6MHz @ U403-Pin4 (Table 50, “USB
Clock Waveform – 6MHz,” on page 77).
• Connect USB cable to UI USB socket and check signal line USB_DET_INT @
U301-Pin24 (Table 9, “Accessories connection indication,” on page 73)
• Observe on the PC Windows’s Explore that “Removable Disk” appear.

Nokia 5510 Specifications

General

Display	Monochrome graphic
Weight	155 g
Keyboard	QWERTY
Network Technology	GSM
2G bands	GSM 900 / 1800
GPRS	No
EDGE	No
Announced	2001
Status	Discontinued
SIM	Mini-SIM
Phonebook	Yes
Call records	10 dialed, 10 received, 10 missed calls
Loudspeaker	Yes
Alert types	Vibration; Downloadable monophonic ringtones
3.5mm jack	No
Games	Yes
Messaging	SMS
Clock	Yes
Alarm	Yes
Infrared port	Yes
Music player	Yes
Radio	Stereo FM radio
Java	No
Dimensions	134 x 58 x 28 mm
Stand-by	55 h - 260 h
Talk time	Up to 4 h 30 min
Colors	Blue
Battery	Removable Li-Ion 950 mAh battery (BLC-2)
