Nokia 600 Service Manual

Nokia 600
RM-701
Service Manual Level 1&2
8
Co nf id e nt ial | Copyright © 2011 Nokia | All rights reserved
V e rsion 1 .0
5. BATTERY INFORMATION
Note: A new battery’s full performance is achieved only after two or three complete charge and
discharge cycles! The battery can be charged and discharged hundreds of times but it will
eventually wear out.
When the operating time (talk-time and standby time) is noticeably shorter than normal, it is
time to buy a new battery. Use only batteries approved by the phone manufacturer and
recharge the battery only with the chargers approved by the manufacturer.
Unplug the charger when not in use. Do not leave the battery connected to a charger for longer
than a week, since overcharging may shorten its lifetime.
If left unused a fully charged battery will discharge itself over time Temperature extremes can
affect the ability of your battery to charge.
For good operation times with Ni-Cd/NiMh batteries, discharge the battery from time to time by
leaving the product switched on until it turns itself off (or by using the battery discharge facility
of any approved accessory available for the product).
Do not attemp t to discharge the battery by any other means Use the ba ttery only for its
intended purpose.
Never use any charger or battery which is damaged.
Do not short-circuit the battery. Accidental short-circuiting can occur when a metallic object
(coin, clip or pen) causes direct connection of the + and - terminals of the battery (meta l str ips
on the battery) for example when you carry a spare battery in your pocket or purse.
Shortcircuiting the terminals may damage the battery or the connecting object.
Leaving the battery in hot or cold places, such as in a closed car in summer or winter conditions,
will reduce the capacity and lifetime of the battery. Always try to keep the battery between 15°C
and 25°C (59°F and 77°F).
A phone with a hot or cold battery may temporarily not work, even when the battery is fully
charged. Batteries’ performance is particularly limited in temperatures well below freezing.
Do not dispose batteries in a f ire! Dispose of batter ies according to local regulations (e.g.
recycling).
Do not dispose as household waste.

Nokia 600 Specifications

General

Announced	2011, August
Status	Discontinued
Network	GSM / HSPA
2G bands	GSM 850 / 900 / 1800 / 1900
3G bands	HSDPA 850 / 900 / 1700 / 1900 / 2100
Speed	HSPA 14.4/5.76 Mbps
GPRS	Class 33
EDGE	Class 33
Weight	100 g (3.53 oz)
SIM	Mini-SIM
Resolution	360 x 640 pixels, 16:9 ratio (~229 ppi density)
Multitouch	Yes
Protection	Corning Gorilla Glass
CPU	1.0 GHz ARM 11
GPU	Broadcom BCM2763
Card slot	microSD, up to 32 GB (dedicated slot)
Video	720p@30fps
Secondary	No
Alert types	Vibration; MP3, WAV ringtones
Loudspeaker	Yes
3.5mm jack	Yes
WLAN	Wi-Fi 802.11 b/g/n
GPS	Yes, with A-GPS
NFC	Yes
USB	microUSB 2.0
Sensors	Accelerometer, proximity, compass
Messaging	SMS, MMS, Email, Push Email, IM
Browser	WAP 2.0/xHTML, HTML, Adobe Flash Lite
Java	Yes, MIDP 2.1
Battery	Removable Li-Ion 1200 mAh battery (BL-4J)
Stand-by	Up to 540 h (2G) / Up to 540 h (3G)
Dimensions	111 x 53 x 13 mm (4.37 x 2.09 x 0.51 in)
Type	16M colors
Platform	Symbian Belle OS
Internal	2 GB
Primary	5 MP
Bluetooth	3.0, A2DP
Radio	Stereo FM radio, RDS
Colors	Black, White, Pink, Blue
