Nokia 6110 Navigator - Page 26

26
CONFIDENTIAL
Copyright © 2007 NOKIA. All rights reserved.
6110 Navigator RM-122
Page (44) ISSUE 4
Service Manual Level 1&2
7. Insert the CAMERA MODULE.
8. Note the correct positioning of the alignment tab.
9. Slightly push it into its place.
10. Insert the SHIELD LID into the C-COVER.
11. Note the correct positioning of the spring contacts as
shown before continue.
12. Place the ENGINE MODULE.
