Start up
Get to know your phone, insert the
battery, SIM card, and memory card, and
learn some important information about
your phone.
Keys and parts
1 Earpiece
2 Display
3 Left and right selection key
4 Navi™ key (scroll key)
5 Call key
6 Keypad
7 Microphone
8 End key
9 Light sensor
10 Charger connector
11 Wrist strap eyelet
12 Nokia AV Connector (3.5 mm)
13 Micro USB cable connector
14 Volume down key
15 Volume up key
16 Loudspeaker
17 Power key
18 Camera flash
19 Camera lens
Install SIM card and battery
Always switch the device off and
disconnect the charger before removing
the battery.
This phone is intended for use with a
BL-5CT battery. Always use original Nokia
batteries.
See "Nokia battery
authentication guidelines", p. 44.
The SIM card and its contacts can be easily
damaged by scratches or bending, so be
careful when handling, inserting, or
removing the card.
1 Slide the cover (1), and remove it.
Remove the battery (2).
6Start up
© 2009 Nokia. All rights reserved.6
