Nokia 6500 Classic Service Manual

3
CONFIDENTIAL
Copyright © 2007 NOKIA. All rights reserved.
6500 classic RM-265
Page (23) ISSUE 1
Service Manual Level 1&2
CHANGE HISTORY1.
Status Version No. Date Comments
Draft 0.1 27.Aug.2007 Initial draft
Approved 1.0 31.Aug.2007 Approval
COPYRIGHT2.
The purpose of this document is to help NOKIA service levels 1 and 2 workshop technicians to carry out service to
NOKIA products. This Service Manual is to be used only by authorized NOKIA service suppliers, and the content of it is
confidential. Please note that NOKIA provides also other guidance documents (e.g. Service Bulletins) for service sup-
pliers, follow these regularly and comply with the given instructions.
While every endeavor has been made to ensure the accuracy of this document, some errors may exist.
If you find any errors or if you have further suggestions, please notify NOKIA using the address below:
CMO Operation & Logistics
Training and Vendor Development
Multimedia Creation & Support
mailto:Service.Manual@nokia.com
Please keep in mind also that this documentation is continuously being updated and modified, so watch always out
for the newest version.
Copyright © 2007 Nokia. All rights reserved.
Reproduction, transfer, distribution or storage of part or all of the contents in this document in any form
without the prior written permission of Nokia is prohibited.
Nokia, Nokia Connecting People, and Nokia X and Y are trademarks or registered trademarks of Nokia
Corporation. Other product and company names mentioned herein may be trademarks or tradenames of
their respective owners.
Nokia operates a policy of continuous development. Nokia reserves the right to make changes and
improvements to any of the products described in this document without prior notice.
Under no circumstances shall Nokia be responsible for any loss of data or income or any special, incidental,
consequential or indirect damages howsoever caused.
The contents of this document are provided “as is”. Except as required by applicable law, no warranties of
any kind, either express or implied, including, but not limited to, the implied warranties of merchantability
and tness for a particular purpose, are made in relation to the accuracy, reliability or contents of this
document. Nokia reserves the right to revise this document or withdraw it at any time without prior notice.
The availability of particular products may vary by region.
IMPORTANT
This document is intended for use by qualied service personnel only.

Nokia 6500 Classic Specifications

General

Display type	TFT
Display diagonal	2 \
Display resolution	240 x 320 pixels
Display number of colors	16.78 million colors
Internal memory	920 MB
Rear camera	Yes
Rear camera resolution	1600 x 1200 pixels
Rear camera resolution (numeric)	2 MP
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Video capture resolution (max)	176 x 144 pixels
Playback formats	AAC, eAAC+, and MP3
Browser supported	WAP 2.0/xHTML
Ringer type	Polyphonic
Polyphonic rings quantity	64
Product color	Black
Talk time (2G)	5.5 h
Battery capacity	830 mAh
Standby time (2G)	300 h
Form factor	Bar
Personal info management (PIM)	Alarm clock, Calculator, Stopwatch, Calendar
Bluetooth version	2.0+EDR
WAP	2.0
Data network	GSM, UMTS, GPRS, 3G
SIM card capability	Single SIM
2G bands (primary SIM)	900, 1900, 850, 1800 MHz
Mobile network generation	3G
USB connector type	Micro-USB
Video formats supported	3GP, H.263, H.264
Body SAR (EU)	0.29 W/kg
Head SAR (EU)	1.1 W/kg
Body SAR (USA)	0.79 W/kg
Head SAR (USA)	0.95 W/kg

Weight and Dimensions

Depth	9.4 mm
Width	44.9 mm
Height	109.7 mm
Weight	93.8 g
