Your device
Keys and parts
1 Light sensor
2 Left selection key
3 Home key
4 Call key
5 Number keys
6 End/Power key
7 Clear key C
8 Right selection key
9 Navi™ key (scroll key)
10 Secondary camera lens
11 Earpiece
12 Wrist strap eyelet
13 Nokia AV connector (2.5 mm)
14 Micro USB connector
15 Charger connector
16 Main camera lens
17 Camera flash
18 Microphone
19 Loudspeaker
20 Capture key
The surface of this device is nickel-free.
Home screen
When you have switched on the
device, and it is registered to a
network, the device is in the home
screen and ready for use.
12 Your device
