CCS Technical Documentation 6-Troubleshooting
Company Confidential NMM-3
Issue 1 (11/2003) Copyright  2003 Nokia Corporation Page 6-31
Company Confidential
Calibration required when components changed
Table 1: Baseband Components
Component ID NMP Code Description Calibration required
D200 4370945 UEME V2.0 Energy management calibration, GSM calibration
R200 1414605 CHIPRES 0R22 Charge calibration
R209 1430187 CHIPRES 100K 1% BSI calibration
D451 4341497 8Mx16 FLASH Energy management calibration
WCDMA/GSM calibration
435C067 Bluetooth Reflash BT-NO CAL
Table 2: WCDMA Component Alignment
WCDMA
TUNINGS
Power
Detector
Cal
RF Channel
Filter Cal
Rx AGC
Alignment
Rx Band
Response
Cal
Tx AGC
Alignment
Tx Band
Response
Cal
Tx PA Bias
Tuning
Temperatu
re Sensor
Cal
REX (N810) NO YES YES YES NO NO NO NO
RX SAW
(Z800)
NO NO NO YES NO NO NO NO
RX VCO
(G800)
NO NO NO NO NO NO NO ON
TEX (N900) NO YES NO NO YES YES NO YES
HEX (N902) NO NO NO NO YES YES NO NO
PA (N960) YES NO NO NO YES YES YES NO
TX VCO
(G900)
NO NO NO NO NO NO NO ON
Isolator
(Z962)
YES NO NO NO YES YES NO NO
TX SAW
(Z900)
NO NO NO NO YES YES NO NO
Duplexer
(Z960)
YES NO YES YES YES YES NO NO
Table 3: GSM Component Alignments
GSM TUNINGS Rx Channel
Select
Filter Cal
Rx Cal
Rx Band
Filter
Response Cal
Rx DtoS
Balance Cal
Tx IQ Tuning
Tx Power
Level Tuning
HELG0 (N600) YES YES YES YES YES YES
PA (N550) NO NO NO NO YES YES
ANT SW (Z500) NO YES YES YES YES YES
VCO (G650) NO NO NO NO YES NO
TX SAW (Z650) NO NO NO NO NO NO
