Nokia C2-03 Service Manual

Confidential Copyright © 2011 Nokia Only for training and service purposes
Page 8 (9) | Component finder bottom | C2-03/C2-06/C2-08 RM-702 | Board: 3ks_40a | v1.0 | 22.06.2011
B
C
D
E
F
G
H
I
J
K
3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21
B
C
D
E
F
G
H
I
J
K
3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21
C2050 H20 C2064 D18 C2105 D7 C2203 F8 C2215 F7 C2409 J8 C3001 F6 C3200 F12 C6011 I10 C7106 G6 C7123 G7 C7138 H7 L2204 E8 L2415 E16 L2427 F 16 L7504 H7 R2054 E18 R2081 J11 R2110 E7 R2209 D15 R2407 G4 R2438 I 10 R3019 H9 R6007 I9 R7104 G5 R7454 D5 V2400 I7 X2000 G17 X7452 C3
A2400 J7 C2051 E18 C2065 C20 C2106 E7 C2204 E9 C2216 E8 C2410 D16 C3009 E10 C3205 G12 C6012 J9 C7107 F6 C7124 H7 C7139 G7 L2051 E19 L2400 J8 L2416 E16 L3000 D7 L7707 I6 R2055 E19 R2082 F11 R2160 H17 R2210 D15 R2411 C18 R2439 C13 R3020 H9 R6008 J8 R7105 G4 R7460 D4 V2401 I7 X2052 G21
A6000 J9 C
2052 G20 C2081 I4 C2107 E7 C2205 G9 C2218 E10 C2411 F16 C3016 F6 C3300 H18 C6019 J9 C7108 H6 C7125 F4 C7456 E4 L2052 E19 L2401 J7 L2417 E16 L3001 D7 R2056 E19 R2083 H4 R2161 H17 R2211 D14 R2412 K6 R2440 C13 R3022 H10 R6009 I9 R7106 G6 V2403 E3 X2080 I5 Z6000 J10
A6001 F5 C2053 E18 C2082 I4 C2108 E7 C2206 E8 C2219 E10 C2412 F16 C3017 G9 C3301 F17 C6020 J9 C7109 H7 C7126 G6 C7460 D4 L2053 D18 L2403 I8 L2418 E16 L3200 F12 M2100 C19 R2057 E18 R2100 D8 R2200 J6 R2212 D15 R2413 C
12 R2441 I8 R3023 H10 R6010 I9 R7107 G5 S2420 C14 V2404 H3 X2400 E16 Z7100 G5
A6002 F8 C2054 F19 C2083 J5 C2109 D7 C2207 F8 C2220 E10 C2500 C8 C3018 G9 C3302 F17 C6192 E17 C7110 G5 C7129 G6 C7461 D5 L2054 D19 L2404 H4 L2419 E16 L3301 G17 R2058 D18 R2101 D8 R2201 I6 R2213 D14 R2414 K5 R2500 C8 R3024 D9 R6191 E18 R7108 G5 S2421 C17 V2405 G3 X2750 H12
C2055 D18 C2084 I4 C2110 D7 C2208 F15 C2400 J8 C2750 G12 C3019 H10 C3307 H19 C6193 E17 C7111 F4 C7130 H7 C7462 D5 L2055 H19 L2405 F15 L2420 F16 L6191 D18 N2000 K5 R2059 D19 R2102 D8 R2202 J6 R2214 C
14 R2415 K5 R2750 J11 R3025 D9 R6193 E18 R7110 F6 S2422 C11 V2406 G3 X2751 I14
B2150 D4 C2056 E18 C2085 J3 C2111 D8 C2209 E8 C2401 J8 C2752 J12 C3020 F7 C3309 F17 C6194 E17 C7113 G5 C7131 H7 L2058 D20 L2406 F15 L2421 D15 L6193 E17 N3000 H9 R2060 E19 R2104 D8 R2203 J6 R2400 I8 R2417 D16 R2755 K12 R3100 I10 R6194 E17 R7112 G4 V2407 B13 X2752 G11
B3000 E6 C2058 G20 C2100 F7 C2165 C6 C2210 E7 C2403 I7 C2753 J12 C3021 F6 C3310 H18 C6195 E18 C
7114 G6 C7132 F6 D2750 K12 L2100 H17 L2410 D15 L2422 D15 L7100 G7 N6000 J9 R2061 D18 R2105 E7 R2204 K6 R2401 I8 R2419 H3 R2761 J12 R3200 F11 R6195 E17 R7113 F6 V2200 J6 V2408 C13 X2753 J12
B7100 H8 C2059 G19 C2101 D8 C2166 C6 C2211 E7 C2405 E15 C2754 J12 C3022 F7 C6005 J9 C6196 E18 C7115 H6 C7133 G6 D3000 F9 L2101 H17 L2411 E15 L2423 E15 L7101 G7 N7100 F5 R2063 G19 R2106 D8 R2205 F12 R2402 I8 R2420 E4 R2762 J12 R3203 F11 R6196 D17 R7114 H8 V2201 J6 V 2409 C18 X3200 E12
C2060 D17 C2102 E7 C2200 G12
C2212 E9 C
2406 E15 C2755 K12 C3023 F7 C6008 J9 C6198 E17 C7117 G4 C7134 G6 D3100 G8 L2150 C6 L2412 E15 L2424 E15 L7106 H7 R2064 G19 R2107 D7 R2206 F12 R2404 G4 R2435 C13 R2763 J12 R3204 G11 R7100 G5 R7115 H7 V2202 F12 V3201 F11 X 3300 G18
C2001 K4 C2062 F7 C2103 D8 C2201 J6 C2213 E7 C2407 E15 C2756 J12 C3027 D7 C6009 I9 C7101 H6 C7120 H6 C7135 I6 L2155 C6 L2413 D16 L2425 E15 L7107 H7 R2003 K5 R2065 F20 R2108 D8 R2207 G12 R2405 F3 R2436 I10 R3004 E9 R3301 H18 R7102 G5 R7116 H8 V2204 E14 V6191 E18 X7450 E4
C
2002 K5 C2063 E18 C2104 E7 C2202 E8 C2214 E7 C2408 F15 C3000 E9 C3028 D7 C6010 I10 C7105 G5 C7121 H7 C7136 H7 F2051 H19 L2201 E8 L2414 E16 L2426 F15 L7451 C4 R2050 H20 R2080 H4 R2109 E7 R2208 F14 R2406 G3 R2437 I10 R3005 D9 R6006 J8 R7103 G5 R7453 E4 V2205 D14 X7451 D3
R
F
X
L
Z
M S
N
D
V
A
B
C
Bottom

Nokia C2-03 Specifications

General

Display type	LCD
Display diagonal	2.6 \
External display	No
Display resolution	240 x 320 pixels
Display number of colors	65536 colors
Internal memory	64 MB
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB
Photo effects	Negative film, Neutral, Sepia
White balance	Auto, Daylight, Fluorescent, Incandescent, Manual
Rear camera resolution	1600 x 1200 pixels
Image formats supported	JPG
Rear camera resolution (numeric)	2 MP
Headphone outputs	1
WAP	2.0
Data network	EDGE, GPRS, GSM
SIM card capability	Dual SIM
GPRS multislot class	12
2G bands (primary SIM)	850, 900, 1800, 1900 MHz
Form factor	Slider
Personalization	Menu, Shortcuts, Themes
Phonebook capacity	1000 entries
Personal info management (PIM)	Alarm clock, Calculator, Calendar, Converter, Events reminder, Notes, Recorder
Email protocols	IMAP4, POP3, SMTP
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Video call	-
Maximum frame rate	15 fps
Video compression formats	3gp, H.263
Video capture resolution (max)	176 x 144 pixels
Ringer type	Polyphonic
Audio formats supported	AAC, AMR, MIDI, MP3, WAV
Talk time (2G)	5 h
Battery capacity	1020 mAh
Standby time (2G)	400 h
Bluetooth version	2.1+EDR
USB connector type	Micro-USB B
Product color	Black

Weight and Dimensions

Depth	17 mm
Width	51.4 mm
Height	103 mm
Volume	78 cm³
Weight	115 g
