31) Remove the A-COVER.
32) Lock the SS-231 to the top MAIN ANTENNA
connector.
33) Lift up the MAIN ANTENNA connector.
34) Lock the SS-231 to the bottom MAIN ANTENNA
connector.
35) Lift up the bottom MAIN ANTENNA connector.
36) Use the tweezers to release the MAIN ANTENNA
connectors from the holding clips.
