Nokia E61i Service Manual

Training and Vendor Development
CMO Operations & Logistics
Multimedia Creation & Support CONFIDENTIAL
23.Feb.2007
11
Service Manual E61i RM-227
Copyright © 2007 NOKIA Corporation. All rights reserved.
Approved 1.0
MGR
Page
(30)
FLS-5 incl. ACF-8, Driver and User Guide
Dongle and flash device incorporated into one package, devel-
oped specifically for POS use.
ACF-8
Universal Power Supply is used to power FLS-4S.
Travel Charger AC-4
Small and lightweight charger for fast charging of your phone
battery.
Internal Battery BP-4L
Inserted under the back cover, this Li-Ion battery provides
power in a lightweight package.
SS-102
Camera removal tool.
CA-53
Service Cable to connect the PC with the Pop-Port™ connector.
SERVICE TOOLS9.

Nokia E61i Specifications

General

Display diagonal	2.8 \
Display resolution	320 x 240 pixels
Display number of colors	16.78 million colors
Ringer type	Polyphonic
Internal memory	60 MB
Rear camera type	Single camera
2G standards	EDGE, GPRS, HSCSD
Data network	3G, csd, wcdma
Bluetooth version	1.2
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Personal info management (PIM)	Calendar, Notes, To-do list
Platform	Symbian
Bundled software	Nokia PC Suite 6.82
Operating system installed	Symbian OS
Form factor	Bar
Product color	White
Talk time (2G)	9 h
Battery capacity	1500 mAh
Standby time (2G)	409 h
Keyboard layout	QWERTY

Weight and Dimensions

Depth	14 mm
Width	70.1 mm
Height	117.1 mm
Weight	150 g
