Nokia G-140W-C User Manual

- 4 -
3 Installation
3.1 Hardware Description
3.1.1 Front Panel
LED Description：
LED
Color
Status
Description
POWER
Off
Power off
Green
Solid
Power on
Green
Blinking
ONTself-test failed
LINK
Off
GPON is down or no link
connected
Green
Solid
GPON link between ONT and
OLT is operating normally
LOS
Off
ONU is NOT authorized
Red
Off
Optical signal is present on
GPON Link
Red
Solid
Optical signal is not present
on GPON link
LAN1-4
Off
ONT power off or Ethernet
not connected
Green
Solid
Ethernet is linked
Green
Flashing
Ethernet link is active and
data is transmitted/received
TEL
Off
No Service
Green
Solid
On Hook
Green
Flashing
Call in or talking
WPS 2.4G/ 5G
Off
WPS disabled
Green
Solid
WPS success
WLAN 2.4G
Off
Wireless is down or no link
connected

Nokia G-140W-C Specifications

General

Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Wi-Fi	802.11 b/g/n
Power Supply	12V DC
Dimensions	140mm
Ports	1 x USB
