Nokia Lumia 800

Service Manual Level 1 and 2
Nokia Lumia 800
RM-801, RM-819
Version 2.0
Product controls and interfaces
3
4
5
6
8
2
1
14
14
15
16
7
10
9
11
12
13
9 — Search key
8 — Start key
7 — Back key
6 — Touch screen
5 — Ambient light & proximity
sensor
4 — Earpiece
3 — Micro SIM card holder
2 — Micro USB connector
1 — Nokia AV 3.5 mm connector
10 — Microphone
11 — Loudspeaker
12 — Camera flash
13 — Camera
14 — Volume keys
15 — Power/Lock key
16 — Camera key
