Nokia Lumia 820 Service Schematics

11 (12) | &RPSRQHQWƬQGHU%RWWRP
Lumia 820 RM-825 | Board: 3VJ_03a | v1.0 | 11.10.2012 | Upknowledge
Nokia Internal Use only | Copyright © 2012 Nokia, Only for training and service purposes
24 23 22 21
24 23 22 21
1920 18 17 1516 14 1213 11 10 9 8 67
19 18 17 1516 14 1213 11 10 9 8 67
5 4 23
H
G
I
J
L
K
M
H
G
I
J
L
K
M
B
A
C
D
E
F
H
G
I
J
L
K
M
B
A
C
D
E
F
H
G
I
J
L
K
M
1
4 23 1
C4209 C19 C4909 C16 L1352 C23 R2700 B11 X3300 G1
B2132 D21 C4220 B20 C4910 D17 L1356 B22 R2701 B11 X4400 K21
C4221 D20 C4950 E16 L1438 I24 R2702 B11 X5200 D7
C1110 L23 C4222 D20 C5200 B7 L2110 B18 R3200 E15 X6301 M23
C1111 L22 C4223 B20 C5201 A7 L2111 B18 R3209 D15 X7800 A23
C1120 D20 C4233 C19 C6500 D22 L2133 D21 R4200 G3 X7802 B6
C1121 C20 C4234 C20 C6501 D2 2 L2151 D5 R4202 B19 X7804 I1
C1122 D20 C4263 B19 C6502 C22 L2152 D5 R4203 B19 X7806 H3
C1123 D20 C4800 C15 C6503 C22 L2160 C5 R4205 C19 X7808 A6
C1140 B
20 C4801 D17 C6504 D23 L2161 H24 R4206 B19 X7809 E1
C1141 C20 C4802 E15 C6505 C22 L2162 I23 R4279 E19 X7811 M4
C1355 C23 C4803 B15 C6507 D23 L2163 H23 R4280 D17 X7812 E3
C1356 C23 C4810 D15 C6510 D22 L2164 H23 R4282 B20
C1364 B23 C4847 C16 C6511 D23 L2165 D5 R4401 I21 Z1350 E14
C1365 B22 C4848 C17 C6513 D23 L2170 I22 R4402 I2 1 Z1351 E14
C1430 J24 C4849 C16 C6514 E2 3 L5200 B8 R4403 I21 Z1352 E14
C1431 I24 C4850 C16 C6515 E23 L6300 L22 R4821 D16 Z2160 H24
C1432 J24 C4851 C16 C6517 E22 L
6500 D23 R4956 C23 Z3300 G3
C2109 B
18 C4854 B16 C6518 E22 L6501 D2 2 R4957 C23 Z3301 F3
C2110 B18 C4855 B17 C6519 E23 L7806 E1 R4958 E16 Z4404 J21
C2135 D20 C4856 C16 C6520 D22 L7807 E1 R5203 B8 Z5200 B8
C2149 C5 C4857 B16 C6522 E22 L7809 F3 R6303 L22
C2151 D5 C4858 B16 C6523 E22 L7811 F2 R6503 E23
C2154 D5 C4859 B16 C6524 E22 L7813 A5 R6504 D23
C2157 E5 C4860 B16 C6527 D23 L7814 I1 R6505 C22
C2158 E5 C4861 D16 C6528 E23 L7821 E2 R6506 E22
C2160 H23 C4862 D16 C6529 E22 L7822 E1 R6507 E23
C2161 H23 C4
863 D17 C7804 I1 L7823 F2 R6530 D23
C2162 I23 C4864 D16 C7815 E1
C2163 I23 C4865 D16 C7820 H3 M2110 C18 V1301 G2
C2164 I2 3 C4866 D16 C7822 E1 V2100 I22
C2165 J22 C4867 D17 C7823 E1 N1110 L23 V2160 I23
C2166 I22 C4868 D16 C7824 H3 N1120 C20 V2161 I23
C2173 D5 C4869 D16 C7831 B
5 N1140 B20 V2162 H23
C2174 D5 C4870 D16 N2150 D5 V3310 G2
C2200 H24 C4872 C16 D 2100 J22 N6500 D22 V4290 E20
C2700 B10 C4873 C17 D3200 C13 N7801 H2 V4404 I21
C3215 B15 C4874 C16 N7802 F2 V5200 B8
C3216 D13 C4875 C16 E3300 D4
C32
17 B
15 C4876 B15 E3301 E4 R1100 H24 X1002 L21
C3218 B15 C4877 B15 E3302 E4 R1350 C22 X1350 B4
C3219 B15 C4893 D15 E3303 F4 R1351 C22 X1351 B22
C4200 G3 C4894 D15 E6500 G24 R1353 C22 X1400 G 22
C4202 C20 C4895 C15 E6501 F23 R2008 L22 X1470 I22
C4203 C19 C4896 C16 R2009 L23 X1471 J22
C4204 B19 C4904 C16 G4200 B22 R2103 H24 X2002 G4
C4207 D19 C4905 D15 R2107 I22 X2160 J23
C4208 D20 C4907 C16 L1301 G2 R2196 H24 X2700 D10
D
E
G
L
M
B
C
N
R
V
X
Z

Nokia Lumia 820 Specifications

General

Processor	Dual-core 1.5 GHz Krait
RAM	1 GB
Internal Storage	8 GB
Expandable Storage	microSD, up to 64 GB
Front Camera	VGA
Dimensions	123.8 x 68.5 x 9.9 mm
Weight	160 g
Colors	Black, Gray, Red, Yellow, White, Blue, Violet
Network	GSM / HSPA / LTE
SIM	Micro-SIM
WLAN	Wi-Fi 802.11 a/b/g/n, dual-band
Bluetooth	3.1, A2DP, EDR
GPS	Yes, with A-GPS, GLONASS
NFC	Yes
USB	microUSB 2.0
Display	4.3 inches, AMOLED, 480 x 800 pixels
Rear Camera	8 MP, Carl Zeiss optics
Battery	1650 mAh, removable
Operating System	Microsoft Windows Phone 8
Radio	FM radio
