12 (12) | &RPSRQHQWƬQGHU)OH[ERDUGV
Lumia 820 RM-825 | Board: 3VJ_03a | v1.0 | 11.10.2012 | Upknowledge
Nokia Internal Use only | Copyright © 2012 Nokia, Only for training and service purposes
LED flex board
AV flex board Sidekey flex board
TOP
TOP
BOTTOM
BOTTOM

Other manuals for Nokia Lumia 820

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Nokia Lumia 820 and is the answer not in the manual?

Nokia Lumia 820 Specifications

General IconGeneral
ProcessorDual-core 1.5 GHz Krait
RAM1 GB
Internal Storage8 GB
Expandable StoragemicroSD, up to 64 GB
Front CameraVGA
Dimensions123.8 x 68.5 x 9.9 mm
Weight160 g
ColorsBlack, Gray, Red, Yellow, White, Blue, Violet
NetworkGSM / HSPA / LTE
SIMMicro-SIM
WLANWi-Fi 802.11 a/b/g/n, dual-band
Bluetooth3.1, A2DP, EDR
GPSYes, with A-GPS, GLONASS
NFCYes
USBmicroUSB 2.0
Display4.3 inches, AMOLED, 480 x 800 pixels
Rear Camera8 MP, Carl Zeiss optics
Battery1650 mAh, removable
Operating SystemMicrosoft Windows Phone 8
RadioFM radio
