PAGE 9 (26) Approved 1.0
CMO Operations & Logistics
MGR
WW Competence Transfer Team
Multimedia Creation & Support CONFIDENTIAL 27.7.2005
Bochum / Germany
7. SERVICE TOOLS
FLS-4S incl. ACF-8, Driver and User Guide
Dongle and flash device incorporated into one package,
developed specifically for POS use.
ACF-8
Universal Power Supply is used to power FLS-4S.
Internal Battery BL-5C
Inserted under the back cover, this Li-Ion 850 mAh battery
provides power in a lightweight package.
DKU-2
USB flash cable
Travel Charger ACP-12
Small and lightweight charger for fast charging of your phone
battery.
Headset HDS-3
Small and lightweight stereo headset for handsfree functionality
and listening to FM radio.
SS-15
Camera removal tool for
Camera Module 2MP. One side is for
disassembly, the other side for assembly.
Service Manual N70 Level 1&2 Copyright © 2005 NOKIA Corporation. All rights reserved.
